Automatic 500ml bottle carbonated soft drink filling machine production line plant manufacture

Products Description


Carbonated Filling Machine DXGF50-50-12

Carbonated drink filling equipment adopts bottle neck holding transmission technology to realize fully automatic bottle rinsing, pulp filling, carbonated filling and cap screwing. It employs single cavity plunger type of fixing filling volume technique. It is equipped with CO2 accuracy pressure control, so that the liquid level is always stable. The application of alarm devices for bottle jam, bottle shortage, bottle damage, cap shortage, over loading etc. in several places ensure the quality of its production. The machine obtains advantages of high reliability, high efficiency, high grade of automation and easy operation etc

Preform feed-in and unscrambler

It adopts the matured worldwide-standardized way of preform feed-in and unscrambling, in which preforms go through preform elevator and are transmitted to preform unscrambler. Inside the preform unscrambler, preforms are automatically sorted and delivered by two inclined revolving cylinders with same speed, and the remaining ones will be picked by star wheel and sent back to preform hopper. The whole process of preform unscrambling is fully automatic and has high efficiency without preform scratches


Automatic 500ml bottle carbonated soft drink filling machine production line plant details

Washing part

Into bottle way is air conveyor direct connection with bottle dial. All 304/316 stainless steel rinse heads, water spray style inject design, more save water consumption and more clean. 304/316 Stainless steel Gripper with plastic pad, ensure minimal bottle crash during washing. 304/316 stainless steel washing pump make the machine more durable

Filling part 304/316 Stainless steel high precision filling nozzle Filling volume adjustable in fine rank, same liquid level after filling All 304/316 stainless steel contact parts & liquid tank, fine polish, no death corner, easy to clean 304/316 stainless steel filling pump Efficient spray nozzle rinse thoroughly and save water for flushing

Automatic 500ml bottle carbonated soft drink filling machine production line plant factory

Automatic 500ml bottle carbonated soft drink filling machine production line plant supplier

Capping part Place and capping system, electromagnetic capping heads, with burden discharge function, make sure minimum bottle crash during capping All 304/316 stainless steel construction No bottle no capping Automatic stop when lack of bottle Capping effect is stable and reliable, Defective rate ≤0.2%

Main technical parameter

Model	DXGF 14-12-5	DXGF 18-18-6	DXGF 24-24-8	DXGF 32-32-8	DXGF 40-40-12	DXGF 50-50-12
Capacity 500ml	2000-3000	3000-5000	5000-7000	8000-9000	10000-12000	12000-14000
Suitable bottle shapes	PET circular
Bottle diameter	50-115mm
Bottle height	160-320mm
Filling type	Isobaric filling
Filling pressure	＜0.4MPa
Rinsing water pressure	＞0.06MPa ＜0.2MPa
Application	Carbonated soft drink bottling line
Total power	4.4kw	5.2kw	6.2kw	7.5kw	8.2kw	11kw
Overall dimensions	2.5*1.9m	2.8*1.9m	3.2*2.2m	3.4*2.5m	4.8*2.3m	5.5*3.3m
Height	2.3m	2.5m	2.5m	2.5m	2.5m	2.5m
Weight	3000kg	4500kg	6000kg	8500kg	10000kg	11000kg

NAME	BRAND	AREA
PLC	Siemens	Germany
INVERTER	Siemens	Germany
CONTACTOR	Siemens	Germany
TOUCH SCREEN	Siemens	Germany
AIR CYLINDER	SMC	Japan
MOTOR	ABB	SWISS
PNEUMATIC PARTS	FESTO	GERMANY
ELECTRICAL PARTS	SCHNEIDER	FRANCE

Turnkey Solution



Juice filling machine


Carbonated drink filling machine


Automatic soft drink production line


Mixed fruit juice mixing system


Mineral water filling machine

Bottle filling packaging machine

Title goes here. Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes

Robot Palletizer Which contribute to the Robotization of the Palletizing system has a compact body and a high throughput. It is suitable for packing bottled drinking water, juice, carbonated soft drinks etc. with production capacity up to 520layer/h. Suitable robot models can be selected according to the work pieces. Payload 110kg, 140kg, 185kg, 315kg, 500kg, 700kg

Company Profile

GRANDEE MACHINE is located in Zhangjiagang City, near Shanghai China. We are expert in the field of liquid packaging machinery in the world. We have more than 10, 000 square meters standard workshop, providing customers with a variety of product development, engineering design, consulting, technical services and other integrated EPC solutions. We are a technology-leading company, have a superior technology and talent team in liquid packaging machinery, electrical, computer engineering, etc. Our main products are blowing filling capping Combiblock, Aseptic cold filling machine, water treatment equipment, drinking water filling machine, juice and carbonated drink production line, can filling and sealing line, complete blowing labeling and packaging system

FAQ

Q1: How to find suitable machine or complete beverage production line? A1: Looking for beverage filling machine in www. grandee machine. en. alibaba. com
•Enquiry: Contact us by email, phone call, fax, Instant Messenger (Trade manager, Skype, WhatsApp, Wechat) and let us know your requirements
• Discussion: Specify the items and what are you exactly looking for

Q2: Are you a trading company or a manufactory? A2: We are the manufacture of water/beverage filling machine and water treatment system over 10 years. We just not only sell drinking water machines and other related equipment, Quality is our culture. We have rich experienced engineers with technicians working team, providing good and after-sales service term, professional salesman terms

Q3: Do you have technical support after we purchased your machines? A3: We will arrange our professional technical to go aboard to your factory, they will help you and teach you how to install and maintenance the machines which you purchased. Or help you to fix machine when it has problems

Q4: If you buy our machines, can you offer us wear-out spare parts? A4: We provide our high quality machine 2 years guarantee, and we will also offer you 2 years wear-out spare parts for free. Once your machines broken or doesn't work within 2 years and you can't solve it, firstly, we will try to help you to find problems from your words description by phone or other communication tolls. Secondly, if the phone solutions still not work, our engineers will go to your factory to solve it. Meanwhile, they will teach you the related experiences for fixing

GRANDEE MACHINE

The Automatic 500ml Bottle Carbonated Soft Drink Filling Machine Production Line Plant is the perfect solution for businesses looking for a reliable and efficient way to produce carbonated soft drinks. This state-of-the-art production line is designed with the latest technology to ensure high-quality output and maximum productivity. The GRANDEE MACHINE 2200 system is an automatic line capable of filling up to 500 bottles per minute. Consequently, businesses can manufacture carbonated beverages in larger volumes at a faster rate. The machine can also measure the exact volume of each bottle, which means the level of fill always remains exactly how it should. Among the main advantages of the production line GRANDEE MACHINE is her simplicity. Built with an operator-friendly interface that makes it easy to control the settings and view what goes on while working. This reduces the amount of training required and makes it suitable for businesses of all shapes and sizes. The production plant of GRANDEE MACHINE series is also durable and serviceable. Made by using the durable materials of high grade that can bear constant heavy duties if used in a production environment. This ensures businesses that they can use the machine for many years to come. The GRANDEE MACHINE production line also introduced the versatility The machine is suitable to fill variety of bottle sizes form 250mL up to 2000 ml. It is a great for producing various carbonated soft drink products including soda, fountain drinks and power.
